Precision Press Brake Tooling Dispatch: Quality Control, Heat Treatment & Selection Guide

Introduction

Recently, JSTMT completed and dispatched a custom shipment of high-precision press brake punches and dies for international sheet metal fabrication clients. Quality tooling is essential for maintaining consistent bend angles, preventing springback errors, and extending machine operational life.

Section 1: Material Selection & Heat Treatment Standard

When selecting press brake tooling for heavy-duty bending, material integrity directly dictates wear resistance and tool deformation limits.

Primary Material (42CrMo / 42CrMo4): High-tensile alloy steel providing exceptional toughness under continuous high-tonnage loads.

Hardening Process: Whole-body heat treatment combined with high-frequency induction hardening along working edges, achieving 47 ± 2 HRC surface hardness.

Wear Resistance: Engineered for processing high-tensile stainless steel, carbon steel, and galvanized sheet metal with minimal edge degradation.

Section 2: Precision Manufacturing & Quality Inspection Log

Before dispatching any tooling set, JSTMT executes a 3-step quality verification process:

Ultrasonic Defect Testing: Inspection of raw forging blocks to rule out internal cracks or air pockets.

CNC Precision Surface Grinding: Clamping grooves and working radii are ground to a precision tolerance within ±0.01mm, allowing seamless sectional tool interchangeability.

Hardness & Angle Verification: Laser-guided angle checks and digital hardness testing across all segments.

Section 3: Export Packaging & Rust Prevention

To ensure tooling arrives in factory-fresh condition without oxidation during long-distance ocean or air freight:

Anti-Rust Oil Coating: Heavy protective oil film applied to all ground surfaces.

VCI Moisture Barrier: Wrapped in Volatile Corrosion Inhibitor (VCI) vacuum packaging.

Plywood Crates: Reinforced fumigation-free wooden packaging anchored with heavy-duty steel strapping.

Section 4: Technical Specifications Summary

Parameter	JSTMT Standard Tooling Specifications
Material Options	42CrMo, 42CrMo4, 55SiCr, SKD11 / LD (High-wear custom options)
Hardness Level	Whole Body Heat Treatment / Edge Hardening (47 ± 2 HRC)
Sectional Lengths	Standard 835mm sets (including 100mm, 200mm, ear segments) & 515mm sets
Interface Compatibility	Amada / Promecam, Wila / Trumpf style, European Standard, LVD style
Machining Tolerance	Parallelism & Linearity ground within ±0.01mm

Press Brake Punch:

• Gooseneck press brake dies: it is usually used for Deep U profile bending with flangs.
• Semi Gooseneck punch
• Straight punch
• Acute Punch

Press Brake Dies：

• 4 way press brake Die block
• 2V Die or single V Die

Hemming Tools

Press Brake Hem die is used to flatten, or First Create hemming bends with an Acute angle punch with 30 degree in the metal,then Place the acute bends metal plate under a flattening tool.

Compatible types: : Amada / Promecam, Trumpf-Wila, LVD, European Standard, American Precision.

Sectionalized Tooling： Standard sectional lengths (e.g., 835mm, 515mm, 100mm segmented sets for fast setup).



UAE shipment -China Press Brake Tooling for Sale

Press Brake Punch and Die sets, 3 Packages  258KGS,  0.1CBM

Vessel: Ever Steady  0166105W  Discharge port: Jebel, Ali

ETD:2023-05-30



Export & Quality Control ：

• Raw Material Inspection: High-grade 42CrMo forging blocks with ultrasonic flaw detection.

• CNC Precision Grinding: Working surfaces and clamping grooves are precision-ground to guarantee seamless alignment.

• Rust Prevention & Packaging: Anti-rust oil coating + heavy-duty vacuum moisture film + export-grade plywood crates.

Explore our full range of standard and custom press brake tooling options compatible with Amada, Trumpf, and LVD systems.

Properly matched tooling ensures maximum bending precision when paired with our hydraulic press brake machines.

FAQ  Questions

Why is 42CrMo steel preferred for press brake tooling?

42CrMo is a high-strength alloy steel offering an excellent balance of toughness and wear resistance. When heat-treated to 47±2 HRC, it resists cracking and plastic deformation under high bending forces



How does JSTMT protect press brake tooling from rust during ocean freight

All Press brake tooling undergoes anti-rust oil coating, vacuum VCI moisture-proof film wrapping, and is packed in heavy-duty fumigation-free wooden crates before container loading.
